High Speed CO2 Flying Online Laser Marking Machine
Production description
|
Model
|
YLH-20F/30F/50F/100F
|
|
Laser source
|
Raycus
|
|
Laser power
|
20W,30W,50W,100W
|
|
Weave length
|
1064 nm
|
|
Marking area
|
110*110mm,175*175mm,220*220mm,300*300mm,500*500mm
|
|
Laser repetition frequency
|
20KHZ-80KHZ
|
|
Beam quality
|
M²:1.5
|
|
Marking speed
|
7000-12000mm/s
|
|
Marking depth
|
0.01-1mm
|
|
Repetition Precision
|
0.01mm
|
|
Minimum Line Width
|
0.017mm
|
|
Minimum Character
|
0.2 mm
|
|
Cooling Style
|
Air cooling
|
|
Positioning Way
|
Red light
|
|
Control software
|
JCZ EZCAD 2.12 Professional fiber laser marking software
|
|
Supported Format
|
PLT, DXF, DST, AI, SDT, BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF,CAD, CDR, DWG and ETC
|
|
Control board
|
JCZ
|
|
Operating Voltage
|
AC220V/50HZ/2A
|
|
Gross Power
|
≤500W
|
|
Supported Windows
|
Windows XP,7,8,10
|
|
Certificate
|
ISO, CE, FDA
|
|
Material can be processed
|
all metal material and part of non-metal material,such as hard plastic
|
|
Others
|
USB cable for connection, Flash drive with software and English manuals.
|
|
After-sales Service
|
Warranty for 3 years.We will send operation video and manual for the machine. Our engineer will do training online. If needed, we can send our engineer to your site for training or you can send the operator to our factory for training. When you have any questions, no matter machine or operate, you can contact us directly.
If any parts broken, we will replace a new one for you in free.
After warranty we will still supply lifetime maintenance in free. Just with parts cost charging if broken.
|
|
Packaging
|
Wooden box
|
|
Packaging Dimension
|
820*770*1670mm
|
|
Gross weight
|
110kg
|
Product features
1. The fiber laser generator is high integrated, has superior laser beam and uniform power density. Output laser power is stable. This design highly increase the machine’s anti-reflection ability with optical isolator, be able to mark on most high reflective materials such as aluminum, copper, gold and silver without the shadow and virtual open phenomenon.
2. Adopts advanced digital high speed scanning galvanometer, quick speed without deviation, small volume, good stability, and performance reached the international advanced level.
3. Modular design, separate laser generator and lifter, more flexible, can mark on bigger area and complicated surface. Air-cooled inside, small occupation, easy to install.
4. Adopt the embedded operating system, which the performance is leading domestic peers, good touch interface and powerful control system, can meet the demand of most industry application process in market.
5. High efficiency for photoelectric conversion, simple operation, Compact in structure, support harsh working environment, no consumables.
6. YLH-20E fiber laser marking machine is portable. Power box and laser source can be separated. Easy transport and can be displayed separately according to user’s site space situation.
